FMUSER DTV-3611C-32/64 32/64 IP(MPTS/SPTS) through 2/4 GE ports(MPTS/SPTS) in 32/64 PAL/NTSC/SECAM Analog RF Modulator
1.Processing of up to 32//64 IP multicast groups of a Gigabit Ethernet MPEG TS into up to 64 standard PAL or NTSC or SECAM TV programs
2.Support BISS De-scrambling (Under developing)
3.Suport CC/Subtitle/Teletext
4.Support OSD (Logo and Caption) insertion for each channel, easy operation
5.64 non-adjacent or adjacent carriers output, each 32 carriers within 400MHz
Details:
FMUSER DTV-3611C-32/64 32/64 IP(MPTS/SPTS) through 2/4 GE ports(MPTS/SPTS) in 32/64 PAL/NTSC/SECAM RF Modulator
Overview:
FMUSER DTV-3611C-32/64 is a IP to RF modulator that can convert up to 32 (or 64) IP channels (or 4 HD/AV+28 IP channels; or 8 HD/AV+24 IP channels) to analog RF output. It also supports OSD (Logo and Caption) insertion for each channel; making it easy to operate; and supports CC/Subtitle/Teletext. Additionally; the product supports BISS de-scrambling; can modify program information; and choose multiple audio options. It has 2/4 GE ports for IP MPTS/SPTS input; with a maximum speed of 840Mbps for each GE input. The product supports HEVC/H.265; H.264/AVC; MPEG-2 TS decoding; and can output 32 (or 64) standard PAL or NTSC or SECAM TV programs via 32 (or 64) non-adjacent or adjacent carriers output within 400MHz. In addition; a redundant power supply is available as an option and it supports web-based network management. Also suitable Cable digital TV adjacent frequency front-end system; hotel IPTV network TV system and hotel satellite digital TV system.
Controlled via web management; with easy updates via web; allowing users to configure the device to meet their specific requirements quickly and easily.
Specification:
Input | Interface/rate | 4 GE ports (max 64 IP input) |
Stream | UDP; UDP / RTP; 1-7 packets (SPTS/MPTS) | |
Transport Protocol | UDP/RTP; unicast and multicast; IGMP V2/V3 | |
Packet Length | 188 / 204 Bytes | |
Decoding | Video | HEVC/H.265; H.264/AVC; MPEG-2 |
Audio | MPEG-1/2 Layer 1/2; (HE-)AAC; AC3 | |
Data | CC; Teletext; Subtitles; DVB Subtitling | |
Resolutions | HEVC/H.265: H.264/AVC: MPEG2: | |
Aspect ratio | 4:3 | |
Modulation | Number of channels | Up to 64 non-adjacent or adjacent carriers output |
Connectors | 75Ω; F-jack | |
Frequency range | 43.25 – 951.252MHz | |
Output Bandwidth | 400MHz(each 32 carriers) | |
Output level | -5 ~ 2dBm (102 ~ 112dBμV) | |
Return loss | ≥ 14dB | |
Spurious frequency dist. | ≥ 60dB | |
Residual carrier accuracy | 1% | |
TV standard | PAL B/G/D/K/M/N/I; | |
Video-signal to noise ratio | ≥ 60dB | |
Carrier to noise ratio | ≥ 60dB (when single carrier on) | |
Network Interface | Management | 1 x 100 Base-T Ethernet (RJ 45) |
Data | 4 x 1000 Base-T Ethernet (RJ 45) | |
Others | Image resolution output | 480i/576i |
OSD | Logo : JPG; BMP; PNG | |
Caption : support multiple languages; scrolling direction and speed customized | ||
Output volume adjustment | 0 - 100 % | |
General | Demission | 483mm×330mm×88mm (WxLxH) |
Temperature | 0~45℃(operation); -20~80℃(storage) | |
Power Supply | AC100V±10%; 50/60Hz |
